Blackmagicdesign HyperDeck Studio User Manual

Using HyperDeck
23
Command Reply No Remote Notes
0x40 0x23 AOutReset Acknowledge Disabled
0x44 0x31 PrerollPreset Acknowledge Disabled
0x40 0x40 AutoModeOff Acknowledge Disabled
ignored, Status bit
remembered
0x40 0x41 AutoModeOn Acknowledge Disabled
ignored, Status bit
remembered
6 - Sense Request
0x61 0x0A TimeCodeGenSense
Request for Gen TC GenTCData Enabled
Timer1Sense Timer1Data Enabled
UserBitsVITCTimeSense UserBitsVITCTimeData Enabled
LTCUserBitsTimeSense LTCUserBitsTimeData Enabled
VITCUserBitsTimeSense VITCUserBitsTimeData Enabled
0x60 0x10 InDataSense InData Enabled
0x60 0x11 OutDataSense OutData Enabled
0x60 0x12 AInDataSense AInData Enabled
0x60 0x13 AOutDataSense AOutData Enabled
0x61 0x20 StatusSense StatusData Enabled
0x60 0x2E SpeedSense SpeedData Enabled
0x60 0x31 PrerollTimeSense PreRollTimeData Enabled
0x60 0x36 TimerModeSense TimerModeData Enabled
0x60 0x3E RecordInhibitSense RecordInhibitStatus Enabled
Supported RS-422 Commands

Blackmagicdesign HyperDeck Studio Specifications

General

Built in Control Panel	Yes
Bit Depth	10-bit
Video Connections	HDMI
Audio Connections	Embedded in SDI/HDMI, XLR
Control	RS-422, Ethernet
Power Supply	Internal
SDI Rates	3G
Computer Interface	Ethernet
SD Video Standards	NTSC, PAL
HD Video Standards	720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60
SDI Compliance	SMPTE 259M, 292M, 424M
HDMI Compliance	HDMI 1.4
Recorder Media	SSD, HDD
External Control	RS-422, Ethernet
Recorder Control	RS-422, Ethernet
Storage	SSD, HDD
Frame Rates	720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Chroma Subsampling	4:2:2
Timecode	Yes
