Blackmagicdesign HyperDeck Studio User Manual

Getting Started
9
Step 3. To skip to the next clip, press the next clip button on the shuttle controls.
Step 4. Press previous clip once to go to the start of the current clip or press twice to skip back to
the start of the previous clip.
If the play button flashes, this means the disk is not fast enough and playback cannot keep up. We
recommend you change to a compressed recording format such as ProRes or DNxHD, or use a faster
recommended SSD for uncompressed or Ultra HD 4K recording.
Congratulations! Your HyperDeck is now up and running. Please continue to the next sections of this
manual for more information on what you can do with your HyperDeck.
SSD slots on HyperDeck Studio models have rotating LEDs to
show the unit is in playback mode.
01:42:56:12
SSD
2
INPUT
DISP
SET
REM
JOG
01:42:56:12
SSD
2
INPUT
DISP
SET
REM
JOG

Blackmagicdesign HyperDeck Studio Specifications

General

Built in Control Panel	Yes
Bit Depth	10-bit
Video Connections	HDMI
Audio Connections	Embedded in SDI/HDMI, XLR
Control	RS-422, Ethernet
Power Supply	Internal
SDI Rates	3G
Computer Interface	Ethernet
SD Video Standards	NTSC, PAL
HD Video Standards	720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60
SDI Compliance	SMPTE 259M, 292M, 424M
HDMI Compliance	HDMI 1.4
Recorder Media	SSD, HDD
External Control	RS-422, Ethernet
Recorder Control	RS-422, Ethernet
Storage	SSD, HDD
Frame Rates	720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
Chroma Subsampling	4:2:2
Timecode	Yes
