Blade 550X - Tail Assembly (T); Step T1: Tail Boom Case and Bearing Assembly; Step T2: Tail Boom Case Securing

10
EN
Step T1Step T1 parts (bag T1)
Step T2 parts (bag T1) Step T2
Hexagonal posts (x6)
Radial bearing
12 X 18 X 4 (x2)
Radial bearing
5 X 10 X 4 (x2)
Brass spacer
Cap head shoulder
bolt M3 X 18 (x4)
M3 Lock nut (x4)
Button head self tapping
screw M3 X 16 (x12)
Tail Assembly (T)
