15.1 Replacement Parts
Replacement parts that can be replaced by the user are shown and listed below. If you need any of these
parts, contact BLU3 directly by referring to diveblu3.com/support or search at the sources of supply listed in the
 SparePartsTablebelowwiththecorrespondingdescriponofthepart.Usethistableforspecialdisposal
 instruconsoftheseparts.
Spare Parts Table
Drip Cap (1), Upper Snorkel Tube (2), Dive
Flag (3), Snorkel Union (4), Lower Snorkel
Tube (5), Snorkel Tube O-rings (6)
Mouthpiece (7) , Mouthpiece Zip Tie (8),
Hose Cu Zip Tie (9)
Harness Aachment Point (10),
Dive Harness (11) Dry Bag Float (12) Baery (13), Baery Charger (14)
6
7
8
9
10
11
12
14
13
15 Parts and Service
Diagram Number Part Name Sources of Supply Descripon Disposal Method
1 Drip Cap Only BLU3 Cap for placement on top of Snorkel Tube Normal
2 Upper Snorkel Tube Only BLU3 Upper half of the Snorkel Tube Normal
3 Dive Flag Only BLU3 Red and white or blue and white colored ag Normal
4 Snorkel Union Only BLU3 Connector piece for two Snorkel Tube halves Normal
5 Lower Snorkel Tube Only BLU3 Lower half of the Snorkel Tube, with o-ring grooves Normal
6 Snorkel Tube O-ring(s) BLU3, O-ring Suppliers, Online Size: 014, Material: EPDM, Durometer: 70A Normal
7 Mouthpiece BLU3, Dives Store, Online Standard diving regulator mouthpiece Normal
8 Mouthpiece Zip Tie BLU3, Hardware Stores, Online UV-resistant, width: 0.19”, length: 8”, tensile strength: 75 lb Normal
9 Hose Cu Zip Tie BLU3, Hardware Stores, Online UV-resistant, width: 0.19”, length: 8”, tensile strength: 75 lb Normal
10 Harness Aachment Point Only BLU3 Two-piece clamp for aaching Dive Harness to Air Hose to user Normal
11 Dive Harness Only BLU3 Neoprene-covered webbing for aaching Air Hose to user Normal
12 Dry Bag Float Only BLU3 Inatable oat for aachment to Nomad Normal
13 Baery Only BLU3 Nomad Baery WEEE
14 Baery Charger Only BLU3 100-240V 50/60Hz Charger for Nomad Baery WEEE
Replacement Parts
3
1
2
5
4
