ACM200 USER MANUAL
44 www.blustream.co.uk / www.blustream.com.au
COMMAND DESCRIPTION COMMAND RESPONSE
Set OUTPUT:xxx From INPUT:yyy (ALL signals routed) OUTxxxFRyyy Set output xxx From INPUT:yyy
Fix VIDEO OUTPUT:xxx From INPUT:yyy OUTxxxVFRyyy Set output video xxx From INPUT:yyy
Fix AUDIO OUTPUT:xxx From INPUT:yyy OUTxxxAFRyyy Set output audio xxx From INPUT:yyy
Fix IR OUTPUT:xxx From INPUT:yyy OUTxxxRFRyyy Set output IR xxx From INPUT:yyy
Fix RS232 OUTPUT:xxx From INPUT:yyy OUTxxxSFRyyy Set output RS232xxx From INPUT:yyy
Fix USB OUTPUT:xxx From INPUT:yyy OUTxxxUFRyyy Set output usb xxx From INPUT:yyy
Fix CEC OUTPUT:xxx From INPUT:yyy OUTxxxCFRyyy Set output cec xxx From INPUT:yyy
Set CEC OUTPUT:yyy ON or O OUTxxxCECON/OFF Set output xxx cec mode ON/OFF
Set OUTPUT:xxx Fast Switching On or O OUTxxxFASTON/OFF Set output xxx fast switching mode ON/OFF
Set OUTPUT:xxx HDR On or O OUTxxxHDRON/OFF Set output xxx hdr mode ON/OFF
Reboot Receiver
OUTxxxRB
Set output xxx reboot and apply all the new
config
Rotate Receiver Video Output
tt=0: clockwise 0 degree rotate
tt=90: clockwise 90 degree rotate
tt=180: clockwise 180 degree rotate
tt=270: clockwise 270 degree rotate
OUTxxxROTATEtt output xxx rotate tt degree
Stretch video Output (keep aspect ratio stretch to fit) OUTxxxSTRETCHON/
OFF
Set output xxx stretch ON/OFF
Switch Receiver (Output) between Matrix and Video Wall
mode
OUTxxxMODEMX/VW Set output xxx to matrix/video wall mode
Receiver HDCP management mode OUTxxxDBGON/OFF Set output xxx debug mode ON/OFF
Set Scaler Output Resolution
0:Bypass
1:2160p@30
2:2160p@24
3:1080p@50
4:1080p@60
5:1080i@50
6:1080i@60
7:720p@60
8:720p@50
9:1280x1024@60
10:1024x768@60
11:1360x768@60
12:1440x900@60
13:1680x1050@60
OUTxxxRESrr
Set output xxx resolution to bypass (=0)
Set output xxx resolution to 2160p@30(=1)
ETC
Single Receiver (output) status OUTxxxSTATUS (See status example at end of document)
Receiver (Output) Commands
