BOCK FK40 Seroes - Removal of the Roller Bearings

Step
12
Removal of the roller bearings
Parts list position: 2150
Tools: Pulling apparatus
Pos. in
parts list
Working course
With the pulling apparatus pull out the roller bearing from the front bearing flange.
2150, 730
Use oil, if necessary!
If a pulling apparatus is not available, the front bearing flange may be heated for approx. 15
minutes in a pre-heated (220°C) baking oven. Afterwards the roller bearing
can be pressed out by hand.
WATCH OUT! Parts are hot! Use protective gloves!
Press out the roller bearing from the compressor body.
Take out the tolerance ring, if there is any.
Use oil, if necessary!
09608-09.03-DGbFEI
- 38 -
2150
312
Fig. 23a
Fig. 23b
