Pos. in
parts list
Working course
Installation of the front bearing flange
Parts list position: 2140
Tools: Allen key 6 mm
Observe the tightening torques (see Table on page 55)!
· Apply oil to the O-ring and place it into the groove in the bearing flange
· Install the front bearing flange with oiled gasket to the body so that the hole for the leak
oil collection ring faces upwards.
· Tighten the screws.
Fig. 34
09608-09.03-DGbFEI
-47-
745
730, 740
750
Step
6
