Install the compressor in the system
Carry out a leak test with refrigerant.
Make a test run. During this, check the oil level, the leak-tightness of the compressor, the
running noise, pressure, temperatures and the functioning of additional devices such as the
capacity regulation.
Checking the compressor
Working course
1. Evacuation/leak check of compressor
Connect the discharge and suction sides of the compressor to a vacuum pump
Evacuate the compressor from both sides; vacuum < 1,5 mbar. Check increase in pressure.
In case there is an increase in pressure, check the compressor for leaks und evacuate again.
Fill in the stipulated amount of oil (2,0 liters).
2. Carrying out the function test
General fastenings with fibrous or metallic flat gaskets
Remark: If the compressor is going to remain in the warehouse, charge it with nitrogen (at about
3 bar pressure) for protection.
Attention! Take the reminders for commissioning in the operating manual for FK
40 into account!
Tightening torques for screwed fastenings
M8 37 Nm
M10 60 Nm
Reminder: Cylinder cover/valve plate:
Tighten the screws cross-wise in at
least two steps (50/100 % of the
tightening torque)
Screw size Tightening torque
Special fastenings
Designation Thread size Tightening torque
1)
With aluminum gasket
Safety valve
Shaft seal cover
Connecting rod screw
Oil filling plug
Oil drain plug
Sight glass
Flanged connection
Soldering gland-shut-off valves
Plugs
Electromagnetic clutch
M24
M8
M6
M22X1,5
1)
M24
NPTF
1
/ 8
M12
M10
37 Nm
15 Nm
60 Nm
25 Nm
60 Nm
25 Nm
85 Nm
60 Nm
