Fan Motor Options
Model Tap #
Default Factory
Motor Setting
CFM
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
CF036
1 FO 964 939 897 865 833 797 763 736 700 676 — —
2 DH 1151 1127 1104 1076 1041 1018 987 955 919 831 — —
3 PL 1040 1006 980 953 924 883 851 824 789 764 — —
4 FL 1306 1286 1264 1243 1216 1188 1146 1051 944 846 — —
5 EH 1408 1386 1365 1342 1311 1258 1181 1078 955 848 — —
CF042
1 FO 1075 1051 1026 994 970 899 860 828 807 781 — —
2 DH 1288 1267 1243 1217 1196 1173 1146 1114 997 935 — —
3 PL 1206 1177 1156 1134 1111 1081 1054 978 942 912 — —
4 FL 1470 1447 1426 1408 1387 1363 1337 1288 1214 971 — —
5 EH 1586 1564 1542 1522 1493 1440 1373 1304 1223 969 — —
CF048
1 FO 1205 1181 1151 1126 1101 1076 1050 1011 923 897 — —
2 DH 1449 1426 1403 1378 1356 1336 1312 1292 1269 1236 — —
3 PL 1301 1273 1252 1229 1205 1182 1155 1125 1092 1004 — —
4 FL 1679 1658 1639 1617 1596 1578 1552 1511 1444 1358 — —
5 EH 1771 1751 1731 1709 1686 1657 1659 1540 1463 1368 — —
CF060
1 FO 1559 1531 1502 1460 1429 1388 1357 1312 1263 1225 1176 1133
2 DH 1857 1823 1801 1769 1737 1707 1673 1643 1611 1569 1536 1486
3 PL 1658 1625 1599 1561 1532 1493 1465 1428 1387 1343 1296 1256
4 FL 2146 2117 2089 2065 2038 2006 1977 1949 1915 1877 1804 1706
5 EH 2236 2205 2176 2149 2119 2088 2067 2027 1981 1916 1824 1728
CF070
1 FO 1656 1610 1578 1544 1496 1461 1412 1378 1340 1272 1184 1131
2 DH 1965 1925 1894 1866 1827 1793 1758 1714 1678 1641 1601 1565
3 PL 1832 1794 1764 1722 1689 1655 1608 1576 1538 1495 1456 1399
4 FL 2253 2219 2190 2159 2125 2099 2068 2033 1992 1956 1920 1883
5 EH 2487 2458 2424 2395 2364 2333 2306 2271 2236 2200 2151 2081
Note: DH = Dehumidification, EH = Electric Heat (when installed), FL = Full Load, FO = Fan Only, and PL = Part Load
Table 13 Constant Torque Motor Performance Data—Horizontal Configuration
Off delay = 30 seconds = After receiving an OFF command
motor will continue running for 30 seconds. CFM based on
wet coil and 1" Merv 5 Throwaway. DH is the default tap for
Dehumidification.
