Bosch CF Series - Horizontal (HZ) Cabinet Options Dimensions

Dimensional Drawings
22.4 Horizontal (HZ) Cabinet Options Dimensions
Table 28 Horizontal (HZ) Cabinet Options Dimensions
Model CF007 CF009 CF012 CF015 CF018 CF024 CF030 CF036 CF042 CF048 CF060 CF070
Economizer
AA
Cabinet +
Economizer
Width (Left Hand
Return)
26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 29” 29” 29” 29”
BB
Cabinet Depth +
Economizer
(Left-Hand
Return)
48.5” 48.5” 48.5” 48.5” 48.5” 48.5” 50.5” 50.5” 57.5” 62” 70” 73”
CC
Cabinet +
Economizer
Width (Right-
Hand Return)
26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 26.5” 29” 29” 29” 29”
DD
Cabinet Depth +
Economizer
(Right-Hand
Return)
48” 48” 48” 48” 48” 48” 50.25” 50.25” 57.25” 58.25” 71” 74”
EE
Economizer
4” 4” 4” 4” 3.75” 3.75” 4” 4” 4” 4” 4” 4”
FF
Economizer Pipe
4.5” 4.5” 4.5” 4.5” 4” 4” 4.25” 4” 4” 3” 4” 4.25”
GG
Economizer
Drain
1.57” 1.57” 1.57” 1.57” 1.65” 1.65” 1.5” 1.5” 1.75” 1.75” 1.25” 1.25”
HH
ECONO Valve
(Right-Hand
Return)
7.35” 7.35” 7.35” 7.35” 8.02” 8.02” 12.5” 12.5” 9.5” 9.5” 12.75” 12.75”
II
ECONO Valve
(Left-Hand
Return)
10.56” 10.56” 10.56” 10.56” 10.72” 10.72” 6.5” 6.75” 12.25” 12.25” 9.25” 9.25”
Filter Rack Options
JJ
1" Filter Rack
1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25” 1.25”
KK
2" Filter Rack
2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25” 2.25”
LL
4" Filter Rack
4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25” 4.25”
MM
Filter Rack
Height
0.92” 0.92” 0.92” 0.92” 0.78” 0.78” 1” 1” 0.75” 0.75” 0.75” 0.75”
NN
R/A Duct Flange
Height
14” 14” 14” 14” 15.25” 15.25” 16” 16” 18” 18” 18” 18”
OO
R/A Duct Flange
Width
22” 22” 22” 22” 23” 23” 28” 28” 32” 32” 42” 46”
Disconnect Switch
QQ
Disconnect
Switch Width
2” 2” 2” 2” 2” 2” 2” 2” 2” 2” 2” 2”
RR
Disconnect
Switch Depth
2” 2” 2” 2” 2” 2” 2” 2” 2” 2” 2” 2”
SS
Disconnect
Switch Height
2” 2” 2” 2” 3” 3” 3” 3” 2” 2” 2” 2”
DDC
TT
DDC Panel Width
9” 9” 9” 9” 9” 9” 9” 9” 9” 9” 9” 9”
UU
DDC Panel Depth
3” 3” 3” 3” 3” 3” 3” 3” 3” 3” 3” 3”
VV
DDC Panel
Height
2.25” 2.25” 2.25” 2.25” 3” 3” 3” 3” 2.25” 2.25” 2.25” 2.25”
HRP
WW
HRP Inlet
N/A N/A N/A N/A N/A 4.75” 4.75” 4.75” 4.75” 4.75” 4.5” 4.5”
YY
HRP Outlet
N/A N/A N/A N/A N/A 7” 7” 7” 7” 7” 7” 7”
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Filt
er rack dimensions does not include 1" duct flange.
• 2" filter racks can accept either a 1" or 2" filter.
• 4" filter racks can accept either a 2" or 4" filter.
• Economizer Drains are 3/4" FNPT.
• HRP Connections are 1/2" FNPT.
96 |
CF Series Heat Pumps — 8733846299 (2024/11)
