Bosch CF Series - Wiring Diagrams; Two-Stage, Single-Phase, Standard Unit with Constant Torque (CT) Motor

Wiring Diagrams
21 Wiring Diagrams
21.1 Two-Stage, Single-Phase, Standard Unit with Constant Torque (CT) Motor
Fig. 29 Two-Stage, Single-Phase, Standard Unit with CT Motor
FOR REFERENCE ONLY Actual unit wiring may vary from this
example. Always refer to the wiring diagram attached to the unit.
78 |
CF Series Heat Pumps — 8733846299 (2024/11)
