Bosch CF Series - Two-Stage, Single-Phase Unit with Optional Components and CT Motor

Wiring Diagrams
21.3 Two-Stage, Single-Phase Unit with Optional Components and CT Motor
Fig. 31 Two-Stage, Single-Phase Unit with Optional Components and CT Motor
FOR REFERENCE ONLY Actual unit wiring may vary from this
example. Always refer to the wiring diagram attached to the unit.
