Bosch CF Series - Corner Weights (Horizontal Cabinets Only)

Specification Tables
20.4 Corner Weights (Horizontal Cabinets Only)
Table 23 Corner Weights (HZ)
Model
Left-Hand Evaporator Right-Hand Evaporator
Total
Left Front* Right Front* Left Back Right Back Left Front* Right Front* Left Back Right Back
CF007 HZ
lbs. 144.0 39.6 35.4 32.2 36.8 35.4 39.6 36.8 32.2
kg. 65.3 18.0 16.1 14.6 16.7 16.1 18.0 16.7 14.6
CF009 HZ
lbs. 136.6 42.4 33.4 28.2 32.6 33.4 42.4 32.6 28.2
kg. 62.0 19.2 15.1 12.8 14.8 15.1 19.2 14.8 12.8
CF012 HZ
lbs. 153.0 42.4 38.4 33.8 38.4 38.4 42.4 38.4 33.8
kg. 69.4 19.2 17.4 15.3 17.4 17.4 19.2 17.4 15.3
CF015 HZ
lbs. 155.0 44.6 38.2 33.8 38.4 38.2 44.6 38.4 33.8
kg. 70.3 20.2 17.3 15.3 17.4 17.3 20.2 17.4 15.3
CF018 HZ
lbs. 173.0 51.8 41.0 37.2 43.0 41.0 51.8 43.0 37.2
kg. 78.5 23.5 18.6 16.9 19.5 18.6 23.5 19.5 16.9
CF024 HZ
lbs. 193.8 47.2 62.2 47.2 37.2 62.2 47.2 37.2 47.2
kg. 87.9 21.4 28.2 21.4 16.9 28.2 21.4 16.9 21.4
CF030 HZ
lbs. 204.2 50.4 61.6 54.0 38.2 61.6 50.4 38.2 54.0
kg. 92.6 22.9 27.9 24.5 17.3 27.9 22.9 17.3 24.5
CF036 HZ
lbs. 205.2 61.6 46.6 40.6 56.4 46.6 61.6 56.4 40.6
kg. 93.1 27.9 21.1 18.4 25.6 21.1 27.9 25.6 18.4
CF042 HZ
lbs. 281.0 70.4 88.0 78.0 44.6 88.0 70.4 44.6 78.0
kg. 127.5 31.9 39.9 35.4 20.2 39.9 31.9 20.2 35.4
CF048 HZ
lbs. 292.0 77.0 89.8 75.6 49.6 89.8 77.0 49.6 75.6
kg. 132.4 34.9 40.7 34.3 22.5 40.7 34.9 22.5 34.3
CF060 HZ
lbs. 324.2 96.7 91.9 71.1 64.7 91.9 96.7 64.7 71.1
kg. 147.1 43.8 41.7 32.2 29.3 41.7 43.8 29.3 32.2
CF070 HZ
lbs. 320.6 108.4 87.2 51.4 73.6 87.2 108.4 73.6 51.4
kg. 145.4 49.2 39.6 23.3 33.4 39.6 49.2 33.4 23.3
*The front is the control box end of the unit.
76 |
CF Series Heat Pumps — 8733846299 (2024/11)
