Bosch CF Series - Motor Setting 0.10 0.20 0.30 0.40 0.50

Fan Motor Options
Model Tap #
Default Factory
Motor Setting
CFM
0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20
CF070
1 1694 1621 1574 1540 1507 1459 1424 1388 1338 1296 1246 1182
2 DH 1941 1913 1883 1846 1813 1783 1756 1715 1684 1651 1606 1571
3 PL 1851 1821 1790 1754 1718 1687 1651 1612 1580 1543 1496 1458
4 FL 2256 2228 2198 2170 2142 2113 2086 2053 2020 1990 1956 1919
5 2491 2466 2440 2409 2381 2352 2321 2292 2262 2230 2197 2161
Note: DH = Dehumidification, EH = Electric Heat (when installed), FL = Full Load, FO = Fan Only, and PL = Part Load
Table 14 Constant Torque Motor Performance Data—Counter-Flow Configuration
Off delay = 30 seconds = After receiving an OFF command
motor will continue running for 30 seconds. CFM based on
wet coil and 1" Merv 5 Throwaway. DH is the default tap for
Dehumidification.
