Bosch CF Series - Dimensional Drawings; Vertical (VT) Unit Dimensions

Dimensional Drawings
22 Dimensional Drawings
22.1 Vertical (VT) Unit Dimensions
Table 25 Vertical (VT) Unit Dimensions
Model CF007 CF009 CF012 CF015 CF018 CF024 CF030 CF036 CF042 CF048 CF060 CF070
Condensate Drain
Connection
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT
Recommended
Replacement Nominal
Filter Size
17" x 19" 17" x 19" 17" x 19" 17" x 19" 18" x 22" 18" x 22" 19" x 27" 24" x 30" 24" x 30" 24" x 30"
18" x 30"
(2 Filters)
18" x 30"
(2 Filters)
Condenser Water
Connections
3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 3/4" FPT 1" FPT 1" FPT 1" FPT
A
Width
21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 24" 24" 24" 24"
B
Depth
21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 21.5" 26" 26" 26" 33" 33"
C
Height
33" 33" 33" 33" 39" 39" 39" 44" 44" 44" 51" 51"
D
Discharge Depth
4" 4" 4" 9.5" 9.5" 9.5" 10.5" 10.5" 10.5" 10.5" 12.5" 12.5"
E
Discharge Width
6.75" 6.75" 6.75" 9.25" 9.25" 9.25" 9.75" 9.75" 10.5" 10.5" 11.75" 11.75"
F
Cabinet Edge to
Discharge
7.25" 7.25" 7.25" 4.25" 4.25" 4.25" 2.25" 5.75" 5" 5" 9" 9"
G
Cabinet Edge to
Discharge
(Left-Hand
Return)
7.5" 7.5" 7.5" 6.25" 6.25" 6.25" 6.25" 5.5" 6.75" 6.75" 6.25" 6.25"
H
Water Inlet
3.5" 3.5" 3.5" 3" 3.25" 3.25" 3.25" 3.25" 3.25" 3.25" 3" 3"
J
Water Outlet
8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.5" 8.25" 8.25"
K
Condensate
Drain
5.75" 5.75" 5.75" 5.75" 6" 6.25" 5.84" 5.75" 5.75" 5.75" 5.75" 5.5"
M
R/A Duct Width
17.5" 17.5" 17.5" 17.5" 18" 18" 16.25" 24" 23.75" 23.75" 27.25" 27.25"
N
R/A Duct Flange
Height
15" 15" 15" 15" 20" 20" 24.75" 28" 28" 28" 34" 34"
P
Filter Rack
Height
17.25" 17.25" 17.25" 17.25" 22.25" 22.25" 22.25" 30" 31.25" 31.25" 37.25" 37.25"
Q
Cabinet Edge to
Discharge
(Right-Hand
Return)
7.5” 7.5” 7.5” 6.25" 6.25" 6.25" 6.25" 5.58" 6.75" 6.75" 6.25" 6.25"
• Specifications subject to change without notice.
• All dimensions within ±0.125".
• Overa
ll unit dimensions do not include filter rack or duct
flanges.
90 |
CF Series Heat Pumps — 8733846299 (2024/11)
