Bosch D9068 - D7033;FMR-DACT-KEYPAD Keypad Programmer; Figure 18: D7033;FMR-DACT-KEYPAD Keypad Programmer

D9068 | Operation and Installation Guide | 4.0 System Operation
28
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
Figure 18: D7033/FMR-DACT-KEYPAD Keypad Programmer
Alarm
Silenced
Power
Trouble
Silence
1 2 3
4 5 6
7 8 9
0
Program
*
#
Command
Disable
History
Test
Drill
Reset
Clear
SYSTEM NORMAL
0: PROGRAM
1
2
3
4
5
6
7
8
9
13
12
10
11
14
15
1 - First line of display
2 - Second line of display
3 - [Reset] key
4 - [Drill] key
5 - [Disable] key
6 - [Test] key
7 - [History] key
8 - [3] key
9 - [6] key
10 - [# Command] key
11 - [0 Program] key
12 - [* Clear] key
13 - [4] key
14 - [1] key
15 - LEDs are not used
