D9068 | Operation and Installation Guide | Appendix C: Fire Communicator Report
Summary
.
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
System
Trouble
Programming
Equipment
Failure
Condition
Equipment Fail Cond
= 011
Refer to Note 1 through Note 9 on page 56
* In Modem IIIa
2
, the D9068 uses Communications Fail to report a Data Lost event. The D9068 reports an
Equipment Fail and Equipment Fail Restore with Condition 006 to report an actual Communications
Fault.
Table 14: Reporting Summaries (Continued)
System
Restore
Programming
Equipment
Restoral Cond = 011
Serial
Communication
Fault
Serial
Communication
Restore
Communication
Trouble
Restoral
Refer to Note 1 through Note 9 on page 56.
Table 15 identifies equipment fail conditions. These conditions appear as a System
Trouble in Contact ID.
On a D9068 that is serially connected to a Bosch Analog FACP, Table 15 only applies
when the reported address
(C for Contact ID, SDI for Modem IIIa
2
) is less then 100. If the reported address
is more than 100, the reported event is a peripheral fault. Refer to Appendix F:
D8024/D10024/D10024A Analog FACP Operation on page 64 for more information.
Table 15: Equipment Fail Conditions
A point configured for Fault on
Open or Fault on Short was
tripped.
The programming keypad was
connected to the D9068.
System Trouble
Programming
Programming was entered on the
D9068.
A control panel fail or restore
occurred.
The control panel was left in the
Programming Mode.
There is an unresolved interrupt
request (IRQ).
There is a fault in wiring loop.
