Bosch D9068 - F.4.6 Analog FACP Event Code to D9068 Report Mapping

D9068 | Operation and Installation Guide | Appendix F: D8024/D10024/D10024A Analog
FACP Operation
70
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
F.4.6 Analog FACP Event Code to D9068 Report Mapping
Table 22 lists the event codes generated by a Bosch D8024 and D10024/D10024A Analog
FACP and the respective D9068 Dialer Report Code.
Table 22: Analog FACP Event Codes
Analog FACP Event Code
Dialer Report
Code
Comments
Low signal output from
detector.
Equipment Fail
– 18
There is a loop wire fault.
High signal from detector.
Point Trouble
1
The sensor is out of calibration.
Pre-alarm signal.
N/A
There is a pre-alarm.
Fire alarm signal.
Point Alarm
1
There is an alarm.
CPU reset.
2
Equipment Fail –
15
The CPU reset.
Commissioning Mode entered.
1
Equipment Fail -
13
The system was left in the Programming
Mode.
Panel reset.
Reset Reboot
The panel reset.
Evacuation from panel keypad.
Fire Drill
There is a fire drill.
Silence alarms.
1
Silence
Interpolated by panel status.
Unconfirmed interrupt from
call point.
Equipment Fail -
16
The sensor failed.
Confirmed interrupt from call
point.
Point Alarm
1
The sensor failed.
Detector contaminated.
Point Dirty
1
The detector is dirty.
No reply from detector.
Point Trouble
1
The detector is not responding.
Digital input signal set from
input unit.
Panel Event
3
There is a peripheral fault.
Detector failed Loop
Overcurrent Test.
Point Trouble
1
The loop is drawing too much current.
External link master failed
to poll.
Equipment Fail -
29
There is a network panel failure.
Detector data corrupted.
Point Trouble
1
There is a data error.
Keypad enabled.
N/A
The keypad is enabled.
Problem with loop wiring.
Equipment Fail -
18
There is a problem with the loop wiring.
Problem with sounder circuit.
Equipment Fail
4
There is a problem with the sounder
circuit.
Problem with power supply.
Equipment Fail
4
There is a problem with the power supply.
Problem with internal memory.
Equipment Fail -
14
There is a problem with the internal
memory.
Earth fault on external
wiring.
Equipment Fail -
17
There is an earth fault on the external
wiring.
Zone is totally disabled.
Equipment Fail -
30
The zone is totally disabled.
No reply from slave panel
data link.
Network Fail
There is no reply from the client panel.
Corrupt reply from slave
panel data link.
Network Fail
There is a data error from the client
panel.
Panel left in Commissioning
Mode
N/A
There was a program switch.
Walk Test commenced.
1
System Test
The Walk Test or Output Test was set from
the panel status.
Zone partially disabled.
Equipment Fail -
30
The zone is partially disabled.
1 The exact message is determined by the point function, such as fire and water flow.
2 Code is not supported at this time.
3 The exact message is determined by the priority reported.
4 The exact message depends on the device type and condition, such as NAC A short and battery fault.
