Bosch D9068 - Appendix B: 4;2 Reporting Codes; Power; Table 13: 4;2 Reporting Codes

D9068 | Operation and Installation Guide | Appendix B: 4/2 Reporting Codes
54
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
Appendix B: 4/2 Reporting Codes
Table 13 lists the 4/2 codes supported by the D9068 Fire Communicator. Refer to
Section 5.4.6 PROG FORMATS, 2: RPT CODES, on page 45 for programming information.
Table 13: 4/2 Reporting Codes
4/2 Report
Code
Keypad
Number Key
Group
Number
Definition
SYSTEM IN TST
1
[1]
1
System in Test. Sent for Walk Test operations.
SYS IN RPT
1
[2]
1
System in Test Restore. Sent for Walk Test operations.
SILENCE
1
[3]
1
Silence. Sent when the [SILENCE] key is pressed.
FIRE DRILL
1
[4]
1
Fire Drill. Sent for fire drill operations.
FIRE DRL RST
1
[5]
1
Fire Drill Restore. Sent for fire drill operations.
OPEN RST RPT
[6]
1
Open Reset Report. Sent when the [RESET] key is pressed.
LOW BATTERY
[7]
1
Low Battery: Sent when a low battery input is active.
LOW BATT RST
[8]
1
Low Battery Restore. Restoral occurs when a low battery
input is active.
AC FAILURE
[9]
1
AC Failure. Sent when an AC Fail input is active.
AC FAIL RST
[1]
2
AC Failure Restore. Restoral occurs for AC Failure.
AUTO TST RPT
[2]
2
Automatic Test Report. Sent for automatic communicator
tests.
OFF NORM TST
[3]
2
Off Normal at Test. Sent if the control panel is off-
normal at the Automatic Test time.
PHONE 1 TRBL
[4]
2
Phone Line 1 Trouble. Sent for Phone Line 1 problems.
PN 1 TRB RST
[5]
2
Phone Line 1 Trouble Restore. Sent for Phone Line 1
problems.
PHONE 2 TRBL
[6]
2
Phone Line 2 Trouble. Sent for Phone Line 2 problems.
PN 2 TRB RST
[7]
2
Phone Line 2 Trouble Restore. Sent for Phone Line 2
problems.
SYSTEM TROUB
1
[8]
2
System Trouble. Sent for general system problems.
SYS TRB RST
1
[9]
2
System Trouble Restore. Sent for general system
problems.
MAN TST RPT
[1]
3
Manual Test Report. Sent for manual communicator tests.
DATA LOST RP
[2]
3
Data Lost Report. Sent if events occur too rapidly.
EEPROM FAIL
[3]
3
EEPROM Failure. Sent for EEPROM problems.
RESET REBOOT
1
[4]
3
System power up and reboot.
SMK PWR TBL
[5]
3
Smoke Power Trouble. Sent for smoke detector power
supply problems.
SMK PWR RSTR
[6]
3
Smoke Power Trouble Restore. Sent for smoke detector
power supply problems.
GND FLT TRBL
[7]
3
Ground Fault Trouble. Sent for ground fault trouble
problems.
GND FLT RSTR
[8]
3
Ground Fault Trouble Restore. Sent for ground fault
trouble problems.
1 Item is sent only when the D9068 is configured to communicate with a Bosch Security Systems, Inc.
D8024 or D10024/D10024A Analog FACP.
