F.4.7 Reported Event to FACP Cause Mapping
Table 23 lists the events generated by a D8024 and D10024/D10024A Analog FACP and
the causes of the events.
Table 23: Analog Reports and Causes
There is a point zone alarm.
There is sprinkler supervisory input.
An alarm from the point is programmed as type =
monitor.
The Walk Test or Output Test entered.
The Walk Test or Output Test exited.
Only Silence reported; resound not reported.
A fire drill initiated (local and remote).
A low battery is detected.
There is an AC Fail (after the control panel and
dialer time-outs).
An Auto Test is in progress.
Control panel trouble occurred when the Test
Report was sent.
There is trouble on Phone Line 1.
There is trouble on Phone Line 2.
The Communications Test is in progress.
There is a communication error.
There is an EEPROM failure.
All trouble and alarms are cleared. This message
is sent when the D9068 receives an all clear
message from the control panel after the control
panel resets.
This message occurs for several trouble type
events. To identify the specific type of trouble
that the condition parameter uses, refer to Table
15 on page 59. Look for the Equipment Fail
(Restore) Reports. Not all events have an
equivalent Equipment Restore message.
