D9068 | Operation and Installation Guide | 1.0 Overview
.
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
9
1.2.8 History Buffer
The D9068 has a history buffer that
retains up to 100 events. Each event is
tagged with the date and time of
occurrence. This buffer can be viewed
when a D7033/FMR-DACT-KEYPAD is
attached to the D9068. When the buffer
is full, old events are discarded to
make room for new events. A watchdog
reset is entered in the buffer and does
not reset the buffer.
The history buffer can clear
when the system loses power
for more than 5 min.
1.2.9 General Specifications
Table 4: General Specifications
Storage/Operating
Temperature
+32°F to +120°F
(0°C to +49°C)
Lightning Protection
Metal oxide
varistors (MOVs)
and spark gaps
provide protection
from lightning
surges and static
discharges for
inputs and
telephone
interface.
1.2.10 Parts List
Table 5 on page 9 identifies the parts
shipped with the D9068.
Table 5: Parts List
Quantity
Part
1
Enclosure
1
Self-tapping screw
1
Self-tapping screw for cover
1
D9068 PC Board in static bag
4
PC Board Mounting screws
4
PC Board mounting clips
4
Sets cable assemblies
2
Sets telco cable assemblies
RJ31X
1
Ground wire
5
2.21 kΩ end-of-line (EOL) resistors; UL
Listed; Bosch (P/N: 25899)
1
Light pipe
Refer to Figure 5 on page 12
for the ground wire
connections. Refer to Figure 6
on page 12 for the cable
assembly connections.
1.2.11 Printed Circuit Board (PCB)
Layout
Figure 1 shows the layout of the D9068
PCB.
