D9068 | Operation and Installation Guide | Appendix E: Report Routing
.
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
63
Appendix E: Report
Routing
The information in this appendix shows
the mapping of point-related (Table 16)
and non-point-related (Table 17) events
to their respective report routing
group, lists the priority level of each
event, and identifies the reporting
limit for specific types of events.
Table 16: Point Related Report Routing
Point-Related Events
Report
Description
Report
Routing
Report
Priority
Point Fire Alarm
NONSUP ALRM
0
Point Waterflow
Alarm
NONSUP ALRM
0
Point
Supervisory
Alarm
SUPVSY ALRM
3
Point Monitor
Alarm
NONSUP ALRM
3
Point Fire
Trouble*
TBL, TBL
RSTR
3
Point Waterflow
Trouble*
TBL, TBL
RSTR
3
Point
Supervisory
Trouble*
TBL, TBL
RSTR
3
Point Monitor*
TBL, TBL
RSTR
3
Point Fire Dirty
Report*
TBL, TBL
RSTR
3
Point Fire
Disable*
TBL, TBL
RSTR
3
Point Fire Alarm
Restore
ALM RSTR,
RST
4
Point Waterflow
Restore
ALM RSTR,
RST
4
Point
Supervisory
Restore
SUPVSY RSTR
4
Point Monitor
Restore
SUPVSY RSTR
4
Point Fire
Trouble Restore*
TBL, TBL
RSTR
4
Point Waterflow
Trouble Restore*
TBL, TBL
RSTR
4
Point
Supervisory
Trouble Restore*
TBL, TBL
RSTR
4
Point Monitor
Trouble Restore*
TBL, TBL
RSTR
4
* Event is limited to a total of 100 reports sent
in a 24-h period. If this limit is exceeded,
the 100th event is replaced with a Data Lost
Report.
Table 17: Non-Point Related Report
Routing
Non-Point-Related Events
Report
Description
Report
Routing
Report
Priority
System Test
TESTS
4
System Test
Restore
TESTS
4
Silence
TESTS
4
Fire Drill
TESTS
4
Open Reset
ALM RSTR, RST
4
Low Battery
1
TBL, TBL RSTR
3
Low Battery
Restore
1
TBL, TBL RSTR
3
AC Fail
1
TBL, TBL RSTR
3
AC Fail Restore
1
TBL, TBL RSTR
3
Auto Test
TESTS
4
Off Normal at
Test
TESTS
4
Phone 1 Trouble
1
TBL, TBL RSTR
3
Phone 2 Trouble
1
TBL, TBL RSTR
3
Phone 1 Restore
1
TBL, TBL RSTR
3
Phone 2 Restore
1
TBL, TBL RSTR
3
Manual Test
2
TESTS
4
Data Lost
TBL, TBL RSTR
6
EEPROM Failure
1
TBL, TBL RSTR
3
System Reset,
Reboot
TBL,TBL RSTR
3
Equipment Fail
1
TBL, TBL RSTR
3
Equipment
Restore
1
TBL, TBL RSTR
3
Network Failure
1
TBL, TBL RSTR
3
Sensor Bus
Failure
1
TBL, TBL RSTR
3
Trouble Input
1
TBL, TBL RSTR
3
Trouble Input
Restore
1
TBL, TBL RSTR
3
System Trouble
Keypad
1
TBL, TBL RSTR
3
System Restore
Keypad
1
TBL, TBL RSTR
3
System Trouble
Comm Fault
1
TBL, TBL RSTR
3
System Restore
Comm Fault
1
TBL, TBL RSTR
3
System Trouble
Programming
1
TBL, TBL RSTR
3
System Restore
Programming
1
TBL, TBL RSTR
3
1 Event is limited to a total of 100 reports sent
in a 24-h period. If this limit is exceeded,
the100
th
event is replaced with a Data Lost
Report.
2 Event resets the count of limited reports and
can send 100 additional reports.
