D9068 | Operation and Installation Guide | Appendix F: D8024/D10024/D10024A Analog
FACP Operation
.
Bosch Security Systems, Inc. | 3/13 | F01U071094-07
3. Connect the earth ground line (green)
on the D9068 to the FACP terminal
labeled “EAR.”
The D9068 draws a maximum of
192 mA. The analog FACP can
provide up to 320 mA. Verify
that the total current draw on
the analog FACP 24 V auxiliary
power is less than 320 mA.
