Electro-static discharges
Electro-Static Discharges (ESD) can damage electric components. Take precautions to prevent
electro-static discharges when touch PCBs.
Figure 2.1: ESD prevention
No.
Description
1 Safety isolating transformer
2 Distribution supply box
3 Conductive compartment trays
4 Electro-static voltage sensor
5 Cotton overall
6 Conductive floor mat
7 Conductive boots/heel grounding protectors
8 Conductive stool
9 Strap (resistance 0.5 to 1.0 MΩ)
10 Common reference point
11 Conductive bench top
12 Supply ground
Table 2.1: ESD prevention
