Control capacity
Active devices
Active devices are devices that can:
– Receive data from the central control unit.
– Transmit data to the central control unit.
Notice!
Active devices must have an address (refer to Initialization, page 178).
Passive devices
Passive devices can only receive data from the central control unit.
Overview
The following table shows the active and passive devices in the DCN.
Device Type
DCN-CON Active
DCN-CONCS Active
DCN-CONFF Active
DCN-CONCM Active
DCN-DDB Passive/Active
DCN-DDI Active
DCN-DISL Active
DCN-DISS Active
DCN-DISCS Active
DCN-DISD Active
DCN-DISDCS Active
DCN-DISV Active
DCN-DISVCS Active
DCN-EPS Passive
DCN-FCS Passive
DCN-FVU Active
DCN-FVU-CN Active
DCN-IDESK Active
LBB4114/00 Passive
LBB4115/00 Passive
Table 4.1: Active and passive devices
4.1.4
