Installation
19 inch units
Install the central control unit in a 19 inch unit rack system or on a flat surface. Four feet and
two brackets are supplied with the central control unit.
Figure 5.1: Installation
Notice!
The central control unit extends 36 mm in front of the brackets, when installed in a rack
system.
5
5.1
Conference System Installation | en 91
Bosch Security Systems B.V. Operation Manual 2013.11 | V2.0 | DCN-NG_OM_V4.x
