Power capacity
Power consumption
The following table shows the power each device in the DCN system uses.
Device Watt
DCN-CON 3.4
DCN-CONCS 3.7
DCN-CONFF 4.2
DCN-CONCM 4.2
DCN-DISL 2.75
DCN-DISS 2.75
DCN-DISCS 2.9
DCN-DISD 2.8
DCN-DISDCS 3.15
DCN-DISV 3.05
DCN-DISVCS 3.20
DCN-IDESK 3.6
DCN-EPS 0.8
DCN-FCS 0.9
DCN-FVU 1.0
DCN-FVU-CN 1.0
DCN-DDB 2.0
DCN-DDI 4.5
LBB4114/00 1.3
LBB4115/00 1.4
Table 4.2: Power consumption
Notice!
The power consumption of the DCN-DDI includes the power consumption of all flush-
mounted devices that you can connect to it.
Power supplies
The devices that supply power to the DCN are the central control unit and the extension
power supply. The power that the central control unit supplies includes the power that the
optical network uses.
4.1.5
Conference System Planning | en 67
Bosch Security Systems B.V. Operation Manual 2013.11 | V2.0 | DCN-NG_OM_V4.x
