Bosch DCN Next Generation - Page 154

VC+
D00
D01
D02
D03
D04
D05
D06
D07
GND
VC+
D08
D09
D10
D11
D12
D13
D14
D15
GND
External On PCB
+
_
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
V 50 V(DC)≤
+
_
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
I 125 mA≤
V 50 V(DC)≤
Figure 6.58: Physical connections
Notice!
The parallel outputs are also available on a20-pole connector (refer to DCN-IDESK Interpreter
Desks, page 50).
Refer to the figure for a circuit diagram for help signaling.
