Figure 5.11: Move the DCN cable
Notice!
The safety of this equipment has been tested according to the standards for moveable
equipment. Before you use this equipment as stationary equipment in a North American
country, contact your supplier.
You can install the discussion unit on a flat surface or in a recess. When you install the
discussion unit desk in a recess:
– Use the template.
– Move the DCN cable to the bottom side of the discussion unit.
Notice!
When you install the discussion unit in a recess, make sure that the delegates or the chairman
can connect the headphones.
When you attach the discussion unit to a flat surface, put screws with a length of 8 mm in the
screw holes (no. 12). The distance between the centres of the screw holes is 34 mm.
Conference System Installation | en 99
Bosch Security Systems B.V. Operation Manual 2013.11 | V2.0 | DCN-NG_OM_V4.x
