Open Line Detection
The implementation of open line detection consists of pull up resistors being ac‐
tivated and deactivated; evaluating the behaviour of the measured value detects
cable breakage, regardless of the pull up resistor being activated by the user.
Open line detection is triggered as shown in the illustration:
12.4.2
12 | Error Memory
120 / 136 DDU S2 PLUS Manual Bosch Motorsport
