Configuring shift LEDs
To use shift LEDs, RPM and gear measurement channels an ECU has to be loaded
in RaceCon.
Tab 'Display'
Tab 'LEDs'
1. Click on the tab ‘LEDs’ in the display view.
2. Click on the button ‘Add shift lights’.
Button 'Add
shift lights'
Tab 'LEDs'
3. The shift light configuration window appears. Set up the shifting lights using
the following configuration possibilities:
8.3.1
Display Configuration | 8
Bosch Motorsport DDU S2 PLUS Manual 33 / 136
