Weight 440 g
Protection Classification IP54 to DIN 40050, Section 9, Issue
2008
Operating temperature internal ‐20 to 85°C
Operating temperature Display ‐20 to 70°C
Max. vibration Vibration profile 1 (see Appendix or
www.bosch‐motorsport.com)
Electrical Data
Supply voltage 8 to 18 V
Max. power consumption (w/o loads) 14 W at 14 V
Inputs
Page/brightness selection Configurable
Analog channels 6
Speed inputs (Hall) 2
Input range 0 to 5 V
Resolution 12 bit
Switchable pull up resistor 3 kOhm
Outputs
Sensor supply 5 V ± 1 % (350 mA) 1
Sensor supply 10 V ± 1 % (350 mA) 1
Environment
External switch for page selection, 12
steps
B 261 209 658‐01
External switch for brightness adjust‐
ment or page selection, 6 steps
B 261 209 659‐01
Connectors and Wires
Motorsport connector
AS 2‐14‐35PN at DDU S2 PLUS
37 pins
Mating connector
AS 6‐14‐35SN
F 02U 000 453‐01
Communication
CAN interfaces 2
Ethernet 100BaseT 2
Sync 1
RS232 1 GPS
