Drag + Drop
A ‘Calculated Speed Wizard’ opens.
Choose device
Choose input source
(internal/external)
Choose driven axle
Choose individual wheel
speed channels
Set limit for speed
difference for calculation
4. Click ‘Finish’ when done.
The speed calculation is inserted into the DDU 8 Project Tree.
Speed calculation
in
Project Tree
Measurement
channels
calculated speed
and calculated
distance
Configuration
window
DDU S2 PLUS
Analog and Frequency Inputs | 10
