Applications Manual FHP560 Controller | 29
Bosch Thermotechnology Corp.
Data subject to changePage____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
26 Zone Temperature eff_zone_temp_1 AV:7 fl oat value 40057 data fl oat 29 ‒‒ ‒

Effective Zone Temperature Status
in °F
27
Hot Gas Reheat
Modulating Valve Status
eff_hgr_mod_vlv1_1 AV:28 fl oat value 40005 data fl oat 14 19 nvoEffHgrModVlv1
SNVT_lev_
percent(81)

Effective Hot Gas Reheat
Modulating Valve Output Status
28 Static Air Fan Speed eff_sa_fan_speed_1 AV:55 fl oat value 40007 data fl oat 15 20 nvoEffSaFanSpeed
SNVT_lev_
percent(81)

Effective Static Air Fan Speed in %
29
Supply Air Duct Static
Pressure
eff_sa_sta_press_1 AV:53 fl oat value 40009 data fl oat 17 ‒‒ ‒

Effective Static Air Pressure Sensor
Status in H2O"
30 Zone CO₂ Level eff_zn_CO₂_lev_1 AV:25 fl oat value 40065 data fl oat 33 ‒‒ ‒

Effective Zone CO₂ Levels in PPM
31
Compressor Enabled
Stages
enabled_clstages_1 AV:68 fl oat value 40023 data fl oat 27 ‒‒ ‒

Compressor Stages Enabled
32
Input Expansion Module
Mode
iem_mode_1 AV:50 fl oat value 40085 data fl oat 63 ‒‒ ‒
IEM Confi guration Setup
0 = Dirty Filter Switch, Fan Status
Switch, Valve End Switch
(Default)
1 = Smoke Detector Switch, Fan
Status Switch, Valve End
Switch
2 = Dirty Filter Switch, Fan Status
Switch, Differential Pressure
Switch
3 = Smoke Detector Switch, Fan
Status Switch, Dirty Filter
Switch
4 = Dirty Filter Switch, Fan Status
Switch, Damper End Switch
5 = Smoke Detector Switch, Fan
Status Switch, Secondary
Drain Pan
6 = Dirty Filter Switch, Fan Status
Switch, Pump Status Switch
7 = None
33
BAS Relative Humidity
Enable/Disable
rh_bas_sel_1 AV:51 fl oat value 40109 data fl oat 80 57 nviRhBasSel
SNVT_count_
inc(9)
RH Sensor Source Selection
0 = BAS RH Sensor
1 = Hard-Wired RH Sensor
(Default)
34
Heating Demand
Percentage
htg_pct_1 AV:12 fl oat value 40073 data fl oat 37 ‒‒ ‒

Heating Capacity in %
35
Mix Air Temperature
Source Status
mat_sel_status_1 AV:84 fl oat value 40025 data fl oat 30 ‒‒ ‒

Mixed Air Temperature Sensor
Source Status
0 = BAS MAT
1 = Wired MAT"
36
Mixed Air Temperature
Sensor
mat_sel_1 AV:85 fl oat value 40019 data fl oat 31 ‒‒ ‒
Mixed Air Temperature Sensor
Source Setup
0 = BAS MAT Sensor
1 = Hard-Wired MAT Sensor
(Default)
37
Minimum Damper
Position
min_mdpr_pos_1 AV:79 fl oat value 40079 data fl oat 40 ‒‒ ‒
Minimum Damper Position Setup
Default = 10% Open
38
Analog Output 2
Options Confi guration
ao2_cfg_sel_1 AV:83 fl oat value 40089 data fl oat 65 52 nviAo2CfgSel
SNVT_count_
inc(9)
Options Confi guration - Controller
Analog Output #2 (AO-2)
0 = Not Used (Default)
1 = Modulating Hot Gas Reheat
Valve Control
Table 25
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
39
Analog Output 1
Options Confi guration
ao1_cfg_sel_1 AV:82 fl oat value 40087 data fl oat 64 51 nviAo1CfgSel
SNVT_count_
inc(9)
Options Confi guration - Controller
Analog Output #1 (AO-1)
0 = Not Used (Default)
1 = Variable Frequence Drive Signal
Control
2 = Mixed Air SCR Preheat Control
3 = SCR Controlled Aux Electric
Heat
40
Mixed Air Temperature
Setpoint
mat_stpt_1 AV:90 fl oat value 40021 data fl oat 32 ‒‒ ‒
Mixed Air Temperature Setpoint
Default: 42 °F, Minimum: 40°F,
Maximum: 60°F
41 Unit Mode Status mode_status_1 AV:24 fl oat value 40027 data fl oat 34 25 nvoModeStatus
SNVT_count_
inc(9)

Unit Mode of Operation Selection
Status
0 = Cooling only
1 = Aux Heat
2 = Heat Pump
3 = Heat Pump + Aux Heat
4 = Heat Pump + Hot Gas Re-Heat
5 = Cooling + Hot Gas Re-Heat"
42
Single Reset/
Free Cooling Reset
Temperature
oat_reset1_1 AV:69 fl oat value 40027 data fl oat 35 ‒‒ ‒
Outside Air Temperature (Free
Cooling Temperature) Operation in
°F or Single Reset Temperature
Default: 50 °F
43
Part Cool Reset
Temperature
oat_reset2_1 AV:72 fl oat value 40029 data fl oat 36 ‒‒ ‒
Outside Air Temperature (Stage 1
Cooling Temperature) Operation
in °F
Default: 60 °F
44
Full Cool Reset
Temperature
oat_reset3_1 AV:74 fl oat value 40033 data fl oat 38 ‒‒ ‒
Outside Air Temperature (Stage 2
Cooling Temperature) Operation
in °F
Default: 75 °F
45
Heating Reset
Temperature
oat_reset_ht_1 AV:92 fl oat value 40035 data fl oat 39 ‒‒ ‒
Outside Air Temperature Reset
Mixed Air (Stage 1 Heating)
Operation in °F Default: 40 °F
46
Temperature Reset
Mode
oat_rst_mode_1 AV:71 fl oat value 40037 data fl oat 41 ‒‒ ‒
Outside Air Temperature Reset
Setup
0 = Single
1 = Multiple (Default)
47
Outside Air
Temperature Sensor
oat_sel_1 AV:73 fl
oat value 40041 data fl oat 42 ‒‒ ‒
Outside Air Temperature Sensor
Source Setup
1 = BAS OAT Sensor
2 = Hard-Wired OAT Sensor
(Default)
48
Outside Air
Temperature Sensor
Source Status
oat_sel_sta_1 AV:78 fl oat value 40029 data fl oat 43 ‒‒ ‒

Outside Air Temperature Sensor
Source Status
0 = BAS OAT Source
1 = Hard-Wired OAT Source
49 Setpoint occ_clg_stpt_1 AV:4 fl oat value 40103 data fl oat 52 9 nviOccClgStpt
SNVT_
temp_p(105)
Occupied Cooling Setpoint Setup
in °F
Default: 74 °F
50 Setpoint occ_htg_stpt_1 AV:2 fl oat value 40105 data fl oat 53 10 nviOccHtgStpt
SNVT_
temp_p(105)
Occupied Heating Setpoint Setup
in °F
Default: 70 °F
Table 26
