FHP560 Controller Applications Manual
Bosch Thermotechnology Corp.
Data subject to change Page____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
51
Occupied Zone
Humidity Setpoint
occ_zhumid_stpt_1 AV:21 fl oat value 40043 data fl oat 44 26 nviOccZhumidStpt
SNVT_lev_
percent(81)
Occupied Humidity Setpoint Setup
in %
Default: 55%, Minimum: 20%,
Maximum: 95%
52
Effect Zone Remote
Temperature
eff_remzone_temp_1 AV:9 fl oat value 40019 data fl oat 25 ‒‒ ‒
Reports the Effective Temperature
from a Zone Remote Temp Sensor
after any offsets have been applied
53 Electric Preheat Output ma_preheat_1 AV:61 fl oat value 40041 data fl oat 85 ‒‒ ‒
SCR Electric Preheat Output for
Mixed Air Control Option in V
54
BAS Relative Humidity
Selection Status
rh_bas_sel_stat_1 AV:57 fl oat value 40045 data fl oat 81 ‒‒ ‒
Relative Humidity Sensor Source
Status
0 = BAS RH Sensor
1 = Hard-Wired RH Sensor
55
Supply Air Static
Pressure High Trip
sa_sta_hi_trip_1 AV:54 fl oat value 40051 data fl oat 46 ‒‒ ‒
High Static Air Pressure Alarm Tip
Setpoint inches of H2O
Default: 2.75 "H2O
56
Temperature Reset
Source
rst_temp_source_1 AV:8 fl oat value 40083 data fl oat 62 ‒‒ ‒
Temperature Reset Source
Selection
0 = Outside Air Temperature Reset
(Default)
1 = Mixed Air Temperature Reset
57 Static Press Setpoint sta_press_stpt_1 AV:52 fl oat value 40053 data fl oat 47 27 nviStaPressStpt
SNVT_
press_p(113)
Static Pressure Setpoint in inches
of H2O Setup
Default: 1.00 "H2O
58
Supply Air Fan Minimum
Speed
saf_min_speed_1 AV:59 fl oat value 40059 data fl oat 48 ‒‒ ‒
Minimum VFD Fan Speed Setpoint
Setup
Default: 40%
59
Supply Air Low
Differential Trip
sat_lo_trip_1 AV:77 fl oat value 40061 data fl oat 49 ‒‒ ‒
Supply Air Temperature Low Trip
Differential Setpoint Setup
Default: 2.0 °F
60
Supply Air Setpoint
Differential
dat_stpt_diff_1 AV:58 fl oat value 40067 data fl oat 51 ‒ ‒‒
Supply Air Temperature Setpoint
Differential Setup
Default: 2.0 °F
61
Supply Air High
Differential Trip
sat_hi_trip_1 AV:63 fl oat value 40063 data fl oat 50 ‒‒ ‒
Supply Air Temperature High Trip
Differential Setpoint Setup
Default: 2.0 °F
62 System Status sys_status_1 AV:16 fl oat value 40031 data fl oat 54 28 nvoSysStatus
SNVT_count_
inc(9)
General System Status
0 = Unoccupied
1 = Occupied
2 = Fan Only
3 = Heating
4 = Cooling
5 = Transition to Cool
6 = Transition to Heat
7 = Air Economizer
8 = Unit Locked
9 = Aux Heat
10 = Re-Heat
11 = Manual Re-Heat
12 = Transition to Re-Heat
13 = Free Cooling
14 = Transition to Free Cooling
15 = Water-Side Economizer
Table 27
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
63 Unit Mode unit_mode_1 AV:23 fl oat value 40069 data fl oat 56 29 nviUnitMode
SNVT_count_
inc(9)
Unit Mode Setup
0 = Cooling only
2 = Heat Pump (Default)
64 Setpoint unocc_clg_stpt_1 AV:3 fl oat value 40131 data fl oat 66 13 nviUnoccClgStpt
SNVT_
temp_p(105)
Unoccupied Cooling Setpoint
Setup in °F
Default: 90 °F
65 Setpoint unocc_htg_stpt_1 AV:1 fl oat value 40133 data fl oat 67 14 nviUnoccHtgStpt
SNVT_
temp_p(105)
Unoccupied Heating Setpoint
Setup in °F
Default: 55 °F
66 Zone CO₂ High Trip zn_CO₂_hi_trip_1 AV:27 fl oat value 40135 data fl oat 68 ‒‒ ‒
Set level of CO₂ reported as a High
Level Alarm
Default: 1200 PPM
67
Zone Humidity Setpoint
Differential
zhumid_stpt_diff_1 AV:22 fl oat value 40071 data fl oat 57 ‒‒ ‒
Zone Humidity Setpoint Differential
Setup in RH %
Default: 2%, Minimum: 1%,
Maximum: 5%
68
Remote Temp or Return
Air Temp Value
zone_rem_sen_val_1 AV:31 fl oat value 40035 data fl oat 58 ‒‒ ‒
Reports the Return Air
Temperature or Zone Remote
Temperature at the Sensor
69
ZS Sensor Combo
Selector
ZS_sen_combo_sel_1 AV:40 fl oat value 40075 data fl oat 59 ‒‒ ‒
ZS Sensor Combination Selection
(sensor must be compatible to
selection)
0 = Temp Only
1 = RH Only
2 = CO₂ Only
3 = Temp + RH
4 = Temp + CO₂
5 = RH + CO₂
6 = Temp + RH + CO₂ (Default)
7 = No ZS Sensor
70 ZS Sensor Enable ZS_sensor_en_1 AV:41 fl oat value 40077 data fl oat 60 ‒‒ ‒
Used to confi gure controller
to recognize a connected ZS
Sensor(s)
0 = No ZS Sensors
1 = ZS Sensors Enabled (Default)
71
ZS Sensor Setpoint
Adjustment Limit
stpt_adj_lim_1 AV:42 fl oat value 40081 data fl oat 61 ‒‒ ‒
"Used to set the allowable range
of setpoint manupilation from a ZS
sensor in the space
Default: +/- 3 °F"
72
Effective Discharge Air
Temperature Setpoint
eff_dat_stpt_1 AV:67 fl oat value 40049 data fl oat 83 ‒‒ ‒
Effective Discharged Air
Temperature Setpoint in °F after
any resets are applied (use this
value when the application involves
Discharge Air Control with Zone
Temp Reset)
Table 28
