Applications Manual FHP560 Controller | 31
Bosch Thermotechnology Corp.
Data subject to changePage____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
73 AO-1 mode status ao1_mode_status_1 AV:101 fl oat value 40037 data fl oat 69 ‒‒ ‒

Reports the option for which
the Controller Analog Output #1
(AO-1) is confi gured
0 = Not Used
1 = Variable Frequence Drive Signal
Control
2 = Mixed Air Preheat using
SCR (for Discharge Air Control
applications only)
3 = SCR Controlled Auxiliary
Electric Heat
74 AO-2 mode status ao2_mode_status_1 AV:102 fl oat value 40039 data fl oat 70 ‒‒ ‒

Reports the option for which
the Controller Analog Output #2
(AO-2) is confi gured
0 = Not Used
1 = Modulating Hot Gas Reheat
Valve Control
75
CO₂ BAS Enable/
Disable
CO₂_bas_ena_1 AV:106 fl oat value 40091 data fl oat 71 53 nviCO₂BasEna
SNVT_count_
inc(9)
CO₂ Sensor Source Selection
0 = BAS CO₂ Sensor
1 = Hard-Wired CO₂ Sensor
(Default)
76
Damper Option
Selection
dmp_opt_sel_1 AV:107 fl oat value 40093 data fl oat 72 ‒‒ ‒
Used to confi gure how on/off
damper is enabled when not
enabled by CO₂
0 = Damper Opens when Fan Runs
(Default)
1 = Damper Opens when Occupied
2 = Damper Opens for Free Cooling
(Air Economizer)
77
Analog Output 3
Options Confi guration
ao3_cfg_sel_1 AV:108 fl oat value 40111 data fl oat 73 60 nviAo3CfgSel
SNVT_count_
inc(9)
Options Confi guration - Controller
Analog Output #3 (AO-3)
0 = Not Used (Default)
1 = Modulating Outdoor Air
Damper Control
78 IN-1 Mode Status ui1_mode_status_1 AV:109 fl oat value 40043 data fl oat 74 ‒‒ ‒

Reports how the controller Input
#1 (IN-1) is confi
gured
0 = Not Used
1 = Static Pressure Sensor
2 = Digital Input Enable (e.g. Room
Occupancy Sensor)
3 = RH Probe Sensor
4 = CO₂ Sensor
79 Input 1 Confi guration in1_cfg_sel_1 AV:110 fl oat value 40095 data fl oat 75 54 nviIn1CfgSel
SNVT_count_
inc(9)
Controller Input #1 (IN-1)
Confi guration Setup
0 = Not Used (Default)
1 = Static Pressure Sensor
2 = Digital Input Enable (e.g. Room
Occupancy Sensor)
3 = RH Probe Sensor
4 = CO₂ Sensor
Table 29
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
80 Input 2 Confi guration in2_cfg_sel_1 AV:111 fl oat value 40097 data fl oat 76 55 nviIn2CfgSel
SNVT_count_
inc(9)
Controller Input #2 (IN-2)
Confi guration Setup
0 = Not Used (Default)
1 = Zone Remote Sensor
2 = Outdoor Air Temperature
Sensor
3 = Entering Water Temperature
Sensor
4 = Mixed Air Temperature Sensor
5 = Relative Humidity Sensor
(Probe)
6 = Digital Enable (e.g. Room
Occupancy Sensor)
7 = Return Air Temperature Sensor
81
Output 4 Options
Confi guration
bo4_cfg_sel_1 AV:112 fl oat value 40099 data fl oat 77 ‒‒ ‒
Options Confi guration ‒ Controller
Binary Output #4 (BO‒4); used
only when unit is confi gured for 1
compressor 1 stage operation (see
AV:114, AV:14)
0 = Not Used (Default)
1 = Hot Gas Reheat for Humidity
Control
2 = Auxiliary Electric Heat Control
3 = Fresh Air Damper Control
82
Output 5 Options
Confi guration
bo5_cfg_sel_1 AV:113 fl oat value 40101 data fl oat 78 56 nviBo5CfgSel
SNVT_count_
inc(9)
Options Confi guration - Controller
Binary Output #5 (BO-5)
0 = Not Used (Default)
1 = Hot Gas Reheat for Humidity
Control
2 = Auxiliary Electric Heat Control
3 = Fresh Air Damper Control
4 = Condenser Water Valve (Loop
Valve) Control
5 = Circulation Water Pump (Loop
Pump) Control
6 = Water-Side Economizer Control
7 = Boilerless Electric Heat Control
83
Override Time
Remaining
tlo_rem_1 AV:115 fl oat value 40047 data fl oat 82 58 nvoTloRem
SNVT_count_
inc(9)

Reports time remaining since ZS
Plus/Pro sensor in the space was
placed in manual override mode
84
Effective ZS Sensor
Temperature
zt_reset_1 AV:116 fl oat value 40051 data fl oat 84 ‒‒ ‒

Effective Zone Temperature reading
from ZS sensor after any offsets
have been applied
85
OAT high limit for Air
Econ
oat_hi_lim_aecon_1 AV:100 fl oat value 40113 data
fl oat 86 ‒‒ ‒
Air Economizer Option: range
setting for Outside Air Temperature
(High Limit) in °F
Default: 60 °F
86
OAT low limit for Air
Econ
oat_lo_lim_aecon_1 AV:117 fl oat value 40115 data fl oat 87 ‒‒ ‒
Air Economizer Option: range
setting for Outside Air Temperature
(Low Limit) in °F
Default: 50 °F
87
Outdoor RH high limit
for Air Econ
rh_hi_lim_aecon_1 AV:118 fl oat value 40117 data fl oat 88 - - -
Air Economizer Option: range
setting for Outside Air Relative
Humidity (High Limit) in %
Default: 50 %
Table 30
