FHP560 Controller Applications Manual
Bosch Thermotechnology Corp.
Data subject to change Page____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
88
Outdoor RH low limit
for Air Econ
rh_lo_lim_aecon_1 AV:119 fl oat value 40119 data fl oat 89 ‒‒ ‒
Air Economizer Option: range
setting for Outside Air Relative
Humidity (Low Limit) in %
Default: 40 %
89 Compressor Status comp_state_1 AV:120 fl oat value 40053 data fl oat 90 ‒‒ ‒
√
Reports compressor state for heat
pump units:
0 = Normal/Off
1 = Compressor Locked
2 = Compressor Overriden ""ON""
3 = Compressor Shutdown/Alarm
90
SCR Electric Heat
Output
mat_pid_1 AV:121 fl oat value 40055 data fl oat 91 ‒‒ ‒

SCR controlled Electric Heat
Output in %
91 Alarm Status alm_status_1 BV:24 discrete in 10002 binary in 2 30 nvoAlmStatus
SNVT_
switch(95)

Network Status indicating alarm
condition in unit (see ""Current
Alarm"" for more information)
0 = System Normal
1 = System in Alarm"
92 Aux Heat Output Cmd aux_htg_cmd_1 BV:20 discrete in 10003 binary in 3 31 nvoAuxHtgCmd
SNVT_
switch(95)

Auxiliary Heat Output Status
0 = Aux Heat Off
1 = Aux Heat On
93
UPM Safety - Brownout
Alarm
brn_2st_1 BV:10 discrete in 10004 binary in 4 32 nvoBrn2st
SNVT_
switch(95)

Brown Out Alarm Status
0 = Normal
1 = BRN Alarm Enabled
94
Occupancy Command
(BAS)
occupancy_cmd_1 BV:1 discrete out 1 binary out 1 12 nviOccupancyCmd
SNVT_
switch(95)
BAS Occupancy Command
0 = Unoccupied (Default)
1 = Occupied (Enables Unit
Operation)
95 Compressor 1 Runtime comp1_rntm_1 BV:35 discrete in 10006 binary in 6 ‒‒ ‒

Compressor 1 Runtime Alarm
0 = Normal
1 = Timer Has Expired
(Default: >8760 Hours)
96 Compressor 2 Runtime comp2_rntm_1 BV:36 discrete in 10007 binary in 7 ‒‒ ‒

Compressor 2 Runtime Alarm
Status
0 = Normal
1 = Timer Has Expired
(Default: >8760 Hours)
97
Compressor 1 Runtime
Reset
cmp1_rntm_rst_1 BV:13 discrete out 2 binar y out 10 35 nviCmp1RntmRst
SNVT_
switch(95)
Compressor 1 Runtime Reset.
Momentary On/Off required.
0 = Reset Off (Default)
1 = Reset On
98
Compressor 2 Runtime
Reset
cmp2_rntm_rst_1 BV:14 discrete out 3 binar y out 11 36 nviCmp2RntmRst
SNVT_
switch(95)
Compressor 2 Runtime Reset.
Momentary On/Off required.
0 = Reset Off (Default)
1 = Reset On
99
Comp Stage1 Output
Cmd
cmp_stg1_cmd_1 BV:11 discrete in 10008 binary in 8 33 nvoCmpStg1Cmd
SNVT_
switch(95)

Compressor Stage 1 Output Status
0 = Compressor 1 Off
1 = Compressor 1 On
100
Comp Stage2 Output
Cmd
cmp_stg2_cmd_1 BV:12 discrete in 10009 binary in 9 34 nvoCmpStg2Cmd
SNVT_
switch(95)

Compressor Stage 2 Output Status
0 = Compressor 2 Off
1 = Compressor 2 On
Table 31
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
101
UPM Safety - High
Condensate Alarm
con_2st_1 BV:9 discrete in 10010 binary in 12 37 nvoCon2st
SNVT_
switch(95)

Condensate Drain Alarm
0 = Normal
1 = Alarm Active
102
Secondary Condensate
Pump Alarm
conpump_1 BV:50 discrete in 10012 binary in 14 ‒‒ ‒

Secondary Condensate Pump
Alarm
0 = Normal
1 = Alarm Active
103 Continuous Fan cont_fan_1 BV:18 discrete out 5 binary out 15 38 nviContFan
SNVT_
switch(95)
Confi gures Fan Operation for
Continuous or Auto
0 = Cycle Fan with Compressor
Operation (Auto)
1 = Continuous Fan Operation
when Occupied or in NSB
(Default)
104
Economizer Cooling
Command
clg_econ_1 BV:92 discrete in 10015 binary in 16 ‒‒ ‒

Cooling Economizer Status
0 = On
1 = Off
105
High Cooling Supply Air
Temperature in DAC
csat_hi_1 BV:86 discrete in 10016 binary in 17 ‒‒ ‒

High Cooling Supply Air
Temperature during Discharge Air
Control Alarm
0 = Normal
1 = Alarm Active
106
Condenser Water Valve
Output
cwv_cmd_1 BV:79 discrete in 10017 binary in 18 ‒‒ ‒

Condenser Water Valve Status
0 = Closed
1 = Open
107
Discharge Air
Temperature Sensor
da_sen_1 BV:31 discrete in 10018 binary in 19 ‒‒ ‒

Discharge Air Temperature Sensor
Alarm
0 = Sensor Normal
1 = Sensor Failure Alarm
108 Damper End Switch des_status_1 BV:93 discrete in 10019 binary in 20 ‒‒ ‒

Damper End Switch Status
0 = Damper Closed
1 = Damper Open
109 Damper Command damper_cmd_1 BV:49 discrete in 10020 binary in 21 39 nvoDamperCmd
SNVT_
switch(95)

Damper Position Output Status
0 = Closed
1 = Open
110
High Discharge Air
Temperature
dat_hi_1 BV:29 discrete in 10021 binary in 22 ‒‒ ‒

Discharge Air Temperature Sensor
Alarm (High Threshold - Cooling)
0 = Normal
1 = Alarm (Default: >70 °F)
111
Discharge Air
Temperature Alarm
dat_lo_1 BV:30 discrete in 10022 binary in 23 ‒‒ ‒

Discharge Air Temperature Sensor
Alarm (Low Threshold - Heating)
0 = Normal
1 = Low DAT Alarm
(Default: <75 °F)
112
Digital Override Lock
Alarm
do_lock_1 BV:37 discrete in 10023 binary in 24 ‒‒ ‒

Digital Override Lock Alarm
0 = Normal
1 = Digital Override Enabled Alarm
113
Differential Pressure
Switch (DPS) Alarm
dps_alarm_1 BV:77 discrete in 10024 binary in 25 ‒‒ ‒

Differential Pressure Switch Alarm
0 = Normal
1 = Alarm
Table 32
