34
|
FHP560 Controller Applications Manual
Bosch Thermotechnology Corp.
Data subject to change Page____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
140
High Static Pressure
Alarm
sas_hi_1 BV:64 discrete in 10053 binary in 57 ‒‒ ‒

Static Air Pressure Alarm (High)
0 = Normal
1 = High Static Pressure
(Default: > 2.75"" H20)
141
Smoke Event Alarm
Notifi cation
smoke_1 BV:81 discrete in 10054 binary in 58 49 nvoSmoke
SNVT_
switch(95)

Smoke Detector Alarm
0 = Normal
1 = Alarm
142 Smoke Event Status smoke_status_1 BV:70 discrete in 10055 binary in 59 ‒‒ ‒

Smoke Alarm Status
0 = Normal
1 = Smoke Detector Active
143 UPM Input Alarm upm_input_1 BV:39 discrete in 10064 binary in 60 ‒‒ ‒

UPM Input Failure Alarm
0 = UPM Connected
1 = UPM Connection Failure
144 UPM Reset upm_rst_1 BV:25 discrete out 9 binary out 61 50 nviUpmRst
SNVT_
switch(95)
UPM Reset.
Momentary On/Off required
0 = Reset Off (Default)
1 = Reset On
145 Valve End Switch Status VES_status_1 BV:68 discrete in 10065 binary in 62 ‒‒ ‒

Valve End Switch Status
0 = Off
1 = Valve End Switch Detected
146 Valve Switch Hand VES_hand_1 BV:150 discrete in 10066 binary in 63 ‒‒ ‒

Valve End Switch Hand Mode
Condenser Water Valve engaged
but not being commanded by
controller.
147 Valve End Switch Alarm VES_fail_1 BV:151 discrete in 10067 binary in 64 ‒‒ ‒

Valve End Switch Fail Alarm
0 = Normal
1 = Active
148 High Humidity Alarm zhumid_hi_1 BV:45 discrete in 10068 binary in 65 ‒‒ ‒

Zone Humidity Alarm (High)
0 = Normal
1 = High Humidity (Default: 10%
above Setpoint)
149 Low Humidity Alarm zhumid_lo_1 BV:46 discrete in 10069 binary in 66 ‒‒ ‒

Zone Humidity Alarm (Low)
0 = Normal
1 = Low Humidity
(Default: 30% below Setpoint)
150
Humidity Sensor
Hardware Failure Alarm
zhumid_sen_1 BV:47 discrete in 10070 binary in 67 ‒‒ ‒

Zone Humidity Sensor Alarm
0 = Normal
1 = Sensor Failure (Check RH
Sensor Hardware
Confi guration)
151
CO₂ Hardware Failure
Alarm
zn_CO₂_fail_1 BV:51 discrete in 10056 binary in 56 ‒‒ ‒

CO₂ Zone Sensor Alarm (Sensor)
0 = Normal
1 = Sensor Failure (Check CO₂
Hardware Confi guration)
152 High CO₂ Alarm zn_CO₂_hi_1 BV:48 discrete in 10057 binary in 57 ‒‒ ‒

CO₂ Zone Sensor Alarm (High)
0 = Normal
1 = High CO₂ Level
(Default: >1200 PPM)
Table 35
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
153
ZS Zone Sensor
Hardware Failure Alarm
zone_sen_1 BV:28 discrete in 10058 binary in 58 ‒‒ ‒

Zone Sensor Failure Alarm
0 = Normal
1 = Sensor Failure (Check: ZS
Sensor Hardware)
154
Remote Temperature
Sensor Hardware
Failure Alarm
zrem_sen_1 BV:43 discrete in 10059 binary in 59 ‒‒ ‒

Remote Temperature Zone Sensor
Failure Alarm
0 = Normal
1 = Sensor Failure (Check Remote
Sensor Hardware)
155
High Remote
Temperature Alarm
zrem_hi_1 BV:41 discrete in 10060 binary in 60 ‒‒ ‒

Remote Sensor Zone Temperature
Alarm (High)
0 = Normal
1 = High Zone Temperature
(Default: 10 °F Above
Setpoint)
156
Low Remote
Temperature Alarm
zrem_lo_1 BV:42 discrete in 10061 binary in 61 ‒‒ ‒

Remote Sensor Zone Temperature
Alarm (Low)
0 = Normal
1 = Low Zone Temperature
(Default: 10 °F Below
Setpoint)
157
High ZS Zone Sensor
Temperature Alarm
ztmp_hi_1 BV:26 discrete in 10062 binary in 62 ‒‒ ‒

Zone Temperature Alarm (High)
0 = Normal
1 = High Zone Temperature
(Default: 10 °F Above
Setpoint)
158
Low ZS Zone Sensor
Temperature Alarm
ztmp_lo_1 BV:27 discrete in 10063 binary in 63 ‒‒ ‒

Zone Temperature Alarm (Low)
0 = Normal
1 = Low Zone Temperature
(Default: 10 °F Below
Setpoint)
159
Duplicate Input 1&2
Alarm
dup_in12_1 BV:2 discrete in 10001 binary in 1 ‒‒ ‒

Duplicated Sensor Confi guration
for IN-1 and IN-2 Alarm
0 = Normal
1 = Alarm (Check input
confi guration for confl icts)
160
Circulation Pump
Output Command
pump_cmd_1 BV:3 discrete in 10005 binary in 5 ‒‒ ‒

Loop Water Pump Status
0 = Pump Running
1 = Pump Off
161
Circulation Pump
Switch Failure Alarm
pss_fail_1 BV:56 discrete in 10047 binary in 49 ‒‒ ‒

Pump Status Switch Fail Alarm
0 = Normal
1 = Active
162 Pump Switch Status pump_status_1 BV:57 discrete in 10048 binary in 50 ‒‒ ‒

Pump Switch Status
0 = Off
1 = Pump Switch Detected
163
Circulation Pump
Switch In Hand Alarm
pss_hand_1 BV:58 discrete in 10049 binary in 51 ‒‒ ‒

Pump Status Switch Hand Mode
Pump running but not being
commanded by controller.
164
Enable/Disable Fan
Status Switch in IEM
allow_fan_alrm_1 BV:67 discrete out 11 binary out 71 ‒‒ ‒
Must be set to enable Fan Status
Switch feature when using IEM
in IN-5
0 = FSS on IEM disabled (Default)
1 = FSS on IEM Enabled
Table 36
