Applications Manual FHP560 Controller | 35
Bosch Thermotechnology Corp.
Data subject to changePage____ of ____
Integration Points
#
Point Description
Name
BACnet MODBUS N2 LON
Read
Only
Description
Name
Type
ID
Object
Type
Register Type ID
SNVT
#
Name SNVT
165
Enable/Disable Valve
Switch in IEM
allow_VES_alrm_1 BV:69 discrete out 12 binary out 72 ‒‒ ‒
Must be set to enable Valve End
Switch feature when using IEM
in IN-5
0 = VES on IEM disabled (Default)
1 = VES on IEM Enabled
166
Smoke Alarm Enable/
Disable
smoke_alrm_enable_1 BV:71 discrete out 14 binary out 74 ‒‒ ‒
Must be set to enable Smoke
Detector Switch feature when
using IEM in IN-5
0 = SDS on IEM disabled (Default)
1 = SDS on IEM Enabled
167 Fan Mode Status fan_mode_status_1 BV:74 discrete in 10071 binary in 68 ‒‒ ‒

Reports the Fan Mode Status set
for the unit
0 = Start/Stop Fan Only
1 = Start/Stop Fan plus VFD
168 BAS Smoke Input bas_smoke_1 BV:75 discrete out 13 binary out 73 59 nviBasSmoke
SNVT_
switch(95)
Smoke Detector Alarm Network
Input (may also be used as
Emergency Shutdown network
point)
0 = Normal (Default)
1 = Alarm/Emergency Shutdown
169 Air Economizer Status aecon_status_1 BV:6 discrete in 10032 binary in 13 ‒‒ ‒

Air Economizer Option Status
0 = Inactive
1 = Active
170
Fan Response for Comp
Lockout
lckout_resp_1 BV:7 discrete out 4 binary out 33 ‒‒ ‒
Confi gures Fan Response during
Compressor Lockout by system
0 = Do not run fan upon
compressor lockout
1 = Run fan upon compressor
lockout (Default)
171 Override Status override_status_1 BV:94 discrete in 10072 binary in 69 ‒‒ ‒

Reports status of override button
on ZS Plus/Pro Sensor
0 = Normal
1 = ZS Sensor in Override Mode
172
Sensor Override
Enable/Disable
enable_push_button_1 BV:95 discrete out 10 binary out 70 ‒‒ ‒
Used to enable or disable ZS Plus/
Pro Sensor Override in the space
0 = ZS Sensor Override NOT
Allowed
1 = ZS Sensor Override Allowed
(Default)
Table 37
