Bosch PRA-CSE - Page 133

PRAESENSA LCD call station | PRA-CSLD, PRA-CSLW | en 133
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
PRA-CSLW
Status business call
Microphone active
Chime/message active
Status emergency call
Microphone active
Alarm tone/message
active
Green
Green blinking
Red
Red blinking
Identification mode /
Indicator test
All LED's blink
Top-side controls
Press-To-Talk Button 4.3" full‑color capacitive
touch screen
LCD
Fixed hand‑held
Press-To-Talk
Microphone
Switch
Bottom-side indicators and controls
100Mbps network 1-2
1Gbps network1-2
Yellow
Green
Device reset (to factory
default)
Button
Bottom-side and side interconnections
Network port 1-2 (PoE
PD)
Local source audio line
input
PRA-CSE
interconnection
