PRAESENSA Power supply module | PRA-PSM24, PRA-PSM48 | en 171
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
16.5.5 Thermal behavior
In the case the ambient temperature exceeds +50°C (for vertical mounting), the load power is
to be reduced by 2.5% per degree Celsius increase in temperature. If the load is not reduced,
the device will run into thermal protection by switching off; the device will go in hick‑up mode
and will recover when the ambient temperature is lowered or the load is reduced as far as
necessary to keep the device within normal working conditions.
16.6 Approvals
Regulatory areas
Safety EN/IEC/CSA/UL 60950-1
Immunity EN 55024
EN 61000-6-1
EN 61000-6-2
Emissions EN 55032
EN 55011
CISPR 32
CISPR 11
FCC‑47 part 15B class B
EN/IEC 61000-3-2, Class A
Conformity declarations
Europe CE
USA/Canada FCC/c-UL/CSA
China CCC
Korea KE
Australia RCM
Taiwan BSMI
Russian Federation EAC
India BIS
Environment RoHS
16.7 Technical data
Electrical
PRA-PSM24
Power transfer
Mains power supply input
Input voltage range
Input voltage tolerance
Frequency range
Inrush current
Power factor (PF)
Leakage current to safety ground
100 to 240VAC
85 to 264VAC
50 to 60Hz
< 35A (115V, 230V)
0.9 to 1.0
< 1mA (240V)
