164 en | Fiber transceiver | PRA-SFPLX, PRA-SFPSX PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
4. Remove the dust plugs from the SFP transceiver optical bores. Immediately attach the LC
fiber cable to the SFP transceiver.
15.5 Approvals
Emergency standard certifications
Europe EN54‑16
International ISO7240‑16
Regulatory areas
Safety Laser Class I IEC60825‑1
Conformity declarations
Europe CE/CPR
USA/Canada FCC/c-UL
Environment RoHS
15.6 Technical data
PRA-SFPSX
Electrical
Interface
Supply voltage 3.3V
Power consumption 0.5W
Speed IEEE802.3z 1000BASE‑SX
Transmitter power -4 to -9.5dBm
Receiver sensitivity <-18dBm
Connection Hot swappable,
Locking
Optical
Interface
Connector type Dual LC
Wave length 850nm
Fiber length
50µm core
62.5 µm core
<550m (1.804ft)
<220m (722ft)
Optical fiber Multi‑mode
Core size 50µm / 62.5µm
