PRAESENSA Call station extension | PRA-CSE | en 145
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
Bottom‑side interconnections
Connection to next
extension (RJ12)
Connection to call
station or previous
extension (RJ12)
13.5 Installation
The PRA-CSE is used in combination with a PRA-CSLD and PRA-CSLW call station.
Refer to
– LCD call station | PRA-CSLD, PRA-CSLW, page 130
13.5.1 Parts included
The box contains the following parts:
Quantity Component
1 Call station extension
1 Bracket (attached to bottom)
1 Metal coupling plate + 4 screws
1 RJ12 interconnection cable
1 Button cap (x3)
1 Quick Installation Guide
1 Important Product Information
No tools or Ethernet cables are provided with the device.
