PRAESENSA Ethernet switch | PRA-ES8P2S | en 157
Bosch Security Systems B.V. Installation manual 2019.11 | V1.00 |
14.5.2 Power supply connection
This Ethernet switch has dual redundant 24 to 48V DC-inputs. In case no battery backup is
required, it can be powered from a PRA-PSM24 or PRA-PSM48 power supply. In case the
switch is used in a Voice Alarm system, compliant to EN54‑16, the switch must be powered
from an EN54‑4 certified power supply, like the PRA-MPS3.
When the switch is powered by the PRA-MPS3 multifunction power supply, it must be
connected to one of the 48V outputs, normally intended for the amplifiers. Use both A and B
outputs for connection redundancy. The 24V output of the PRA-MPS3 is not powerful enough
for this switch. The 48V output that is powering the switch should not be used to also power
an amplifier. Especially when the switch is serving multiple PoE powered devices as PSE
(Power Sourcing Equipment), its power consumption can raise to 140W. The remaining
power capacity of the 48V supply is not sufficient anymore for an amplifier under various load
conditions.
The lifeline that belongs to the powering 48V output is not used, so the 48V output will not
be disabled as would be for amplifiers in sleep/snooze mode to save power. It is also essential
that the 48V for the switch is not disabled at any time. In case of mains failure the switch will
be powered from the battery, connected to the multifunction power supply.
14.5.3 Fault relay connection
The switch has a fault relay output to report faults. This relay can be connected to one of the
control inputs of the PRA-MPS3, configured as ‘External fault input’, to transfer switch faults
to the PRAESENSA system. This switch does not communicate via OMNEO to the PRAESENSA
system controller.
14.6 Approvals
Emergency standard certifications
Europe EN54‑16
International ISO7240‑16
Regulatory areas
Safety UL508
Immunity EN55024
EN61000‑4‑2
EN61000‑4‑3
EN61000‑4‑4
EN61000‑4‑5
EN61000‑4‑6
EN61000‑4‑8
Emissions EN55032 classA
EN61000‑6‑4
FCC‑47 part 15B classA
Railway EN50121‑4
Shock IEC60068‑2‑27
Freefall IEC60068‑2‑32
Vibration IEC60068‑2‑6
