170 en | Power supply module | PRA-PSM24, PRA-PSM48 PRAESENSA
2019.11 | V1.00 | Installation manual Bosch Security Systems B.V.
16.5.3 Mains connection
The terminal block connector allows for easy and fast wiring.
For connecting the mains power to the power supply, follow the procedure below:
1. Use standard flexible (stranded wire) or solid cables with a cross section of 0.75 to
2.5mm² (AWG18 to 14), designed to sustain an operating temperature of 75°C (167°F).
2. For secure and reliable connections, the stripping length should be 7mm.
3. For safety, ensure that all wires are fully inserted into the connecting terminals. In
accordance to EN60950 / UL60950, flexible cables require ferrules.
4. Fix the L (Live), N (Neutral) and PE (Protective Earth) connection wires to the input
terminal connector to establish the 100 to 240VAC connection, using a torque of 0.5Nm.
5. Plug the connector into the power supply.
The unit is protected with an internal fuse (not replaceable) at the L input and the power
supply has been tested and approved on 20A (UL) and 16A (IEC) branch circuits without an
additional protection device. An external protection device is only required if the supplying
branch has a current capability greater than this. Thus, if an external protective device is
necessary or utilized, a circuit breaker must be used with a minimum value of 4A (B-
characteristic) or 2A (C‑characteristic).
!
Caution!
The internal fuse must not be replaced by the user. In case of an internal defect, return the
unit for inspection.
16.5.4 Output connection
Use the positive (+) and negative (-) screw connections to establish the 24V (PRA-PSM24) or
48V (PRA-PSM48) connection. The output voltage can be adjusted upwards to 28V or 56V
with the front side potentiometer, but for use with PRAESENSA keep the power supply at 24V
or 48V. The green LED DC OK displays the correct functioning of the output. The device has a
short circuit and overload protection and an overvoltage protection.
For connecting the output to a PRAESENSA device, proceed as follows:
1. Use a PRA-PSM24 to power a PRA-SCx system controller or auxiliary device designed for
24V operation.
2. Use a PRA-PSM48 to power a PRA‑AD60x multi-channel amplifier or PRA-ES8P2S Ethernet
switch, designed for 48V operation.
3. Use standard flexible (stranded wire) or solid cables with a cross section of 1.5 to
2.5mm² (AWG16 to 14), designed to sustain an operating temperature of 75°C (167°F).
4. For secure and reliable connections, the stripping length should be 7mm.
5. For safety, ensure that all wires are fully inserted into the connecting terminals. In
accordance to EN60950 / UL60950, flexible cables require ferrules.
6. Use a torque of 0.5Nm on the screws to secure the wire connections.
7. For cable redundancy use two cables in parallel (2x2 wires) between the dual output
connections of the power supply and the A and B inputs of the loads to be connected.
In the event of a short circuit or overload, the output voltage and current collapses when the
overload current exceeds 150% of the maximum output current. The output voltage is then
reduced and the power supply enters the hick‑up mode until the short circuit or overload has
been removed.
