Diagnosis
Logamatic EMS – 6 720 801 387 (2011/05)
46
7
7 Diagnosis
The diagnosis service menu contains a number of tools for diagnosis:
• Function test:
1), 2)
• Monitor value
• Fault display:
3)
• Heating curve
•Versions
B Press + + simultaneously, to open the SERVICE MENU.
B Turn the rotary selector to the left until diagnosis is selected.
B Press to open the SERVICE\DIAGNOSIS menu.
1) this function is only possible to a limited extent with boilers with UBA-H3
2) This function is not possible or not available with boilers with UBA1.x or DBA.
3) this function is only possible to a limited extent with boilers with DBA, UBA1.x or UBA-H3.
Note that the menu items shown will vary depending on the heating system.
SERVICE MENU
quick operation
settings
diagnosis
servicing
B
