Diagnosis
Logamatic EMS – 6 720 801 387 (2011/05)
48
7
7.2 Monitor value
You can use the monitor value menu to view the set and actual values for the heating system. The
set value will be displayed first and then the actual value. The values displayed for monitoring
purposes vary depending on the system installed.
If the values to be displayed do not all fit on the screen, they are displayed as a list. The
list can be moved up or down by turning rotary selector.
DIAGNOSIS\MON. VALUE Other information
Boiler / burner
MCM10/cascade Only in conjunction with MCM10 (instead of "boiler/burner")
Boiler:
1)
1) the monitor values for each boiler / heat generator are depicted in their own screen. Call up the monitor
values for the next boiler by turning the rotary selector. Symbol present = the corresponding function is
active. Explanation of symbols Æ Tab. 21, page 49.
Only in conjunction with MCM10 (instead of "boiler/burner")
Hybrid Only in association with HM10 (in place of “boiler/burner”)
Heat generator
1)
Only in association with HM10 (in place of 'boiler/burner')
Pump module
Low loss header
2)
2) Not possible or not available with boilers with UBA1.x or DBA.
DHW
Heating circuit 1 Values are displayed for additional heating circuits,
if these are installed.
Solar
2)
Module UM10
2)
for solid fuel boiler; EV2 = external locking (entry)
Wireless transm.
2)
FB = strength of the wireless signal
Bus users
2)
Table 20 Navigator for service menu DIAGNOSIS\MONITOR VALUE
