32/83 ctrlX SAFETY | Commissioning
R911405651, Bosch Rexroth AG, DOK-XSAFE*-SAFEX-C.1XC-IT03-EN-P, Edition 03
7.3 Switch-on sequence and device status
After each restart of the ctrlX SAFETY compact safety controller, the following phases are
run through with error-free operation and displayed as the device status in the ctrlX SAFETY
Engineering programming software:
Tabelle 15: LED device diagnostics (Lightpipe, PF01)
PF01 Startup phase,
device status
Color Flashing
pattern
Meaning
- - Off No voltage supply
Init,
Self-test,
Stop,
BusInit
Yellow Flashing The controller is in the
startup phase or STOP or
a program/firmware
download is being
performed.
RunIntern Yellow Permanently
illuminated
Local operation of the
device as FSoE master
(FSOE slave user not yet
in Run)
Run Green Flashing The controller is
functioning correctly; the
application is running, but
has not (yet) been
validated.
Run Green Permanently
illuminated
The controller is
functioning correctly; the
application is running and
validated.
Alarm Red Flashing Alarm (application error) -
the device is in a safe
operating state. Error
status and safety program
can be reset.
1)
Error Red Permanently
illuminated
Fatal error - the device is in
a safe operating state. The
error state can only be
reset via POR.
