Bose FreeSpace DXA 2120 Service Manual

15
ELECTRICAL PART LIST
LEDs
Control PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
LED401 LED, SLR342-MG3F, GN (ROHM) 3700-2570+G 4
LED402 LED, SLR342-MG3F, GN (ROHM) 3700-2570+G 4
LED403 LED, SLR342-MG3F, GN (ROHM) 3700-2570+G 4
LED404 LED, SLR342-MG3F, GN (ROHM) 3700-2570+G 4
LED405 LED, CY, D3X8, GN 3700-3616+G 4
LED406 LED, CY, D3X8, GN 3700-3616+G 4
LED407 LED, CY, D3X8, GN 3700-3616+G 4
LED408 LED, CY, D3X8, GN 3700-3616+G 4
LED409 LED, SC, 3.1X3.8, L0.4, RD 3700-1530+R 4
LED410 LED, SC, 3.1X3.8, L0.4, RD 3700-1530+R 4
LED411 LED, SC, 3.1X3.8, L0.4, RD 3700-1530+R 4
LED412 LED, SC, 3.1X3.8, L0.4, RD 3700-1530+R 4
LED413 LED, CY, D3X8, RD 3700-3617+R 4
LED414 LED, CY, D3X8, RD 3700-3617+R 4
LED415 LED, CY, D3X8, RD 3700-3617+R 4
LED416 LED, CY, D3X8, RD 3700-3617+R 4
LED421 LED, CY, D3X8, BL 3700-3615+B 4
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
VR408 VR, 20KBX2, RV09ACF-40-15B, SCREW ADJ 4751-1250+0 4
VR409 VR, 20KBX2, RV09ACF-40-15B, SCREW ADJ 4751-1250+0 4
VR410 VR, 20KBX2, RV09ACF-40-15B, SCREW ADJ 4751-1250+0 4
VR411 VR, 20KBX2, RV09ACF-40-15B, SCREW ADJ 4751-1250+0 4
VR405 VR, ROTARY, 20KB, L20 SHAFT, 40 TEETH,
RV09ACF-40-20K
4751-1260+0 4
VR406 VR, ROTARY, 20KB, L20 SHAFT, 40 TEETH,
RV09ACF-40-20K
4751-1260+0 4
VR407 VR, ROTARY, 20KB, L20 SHAFT, 40 TEETH,
RV09ACF-40-20K
4751-1260+0 4
VR401 VR, ROTARY, 20KB, L25, SHAFT, FLAT,
RV09ACF-40-25F
4751-1270+0 4
VR402 VR, ROTARY, 20KB, L25, SHAFT, FLAT,
RV09ACF-40-25F
4751-1270+0 4
VR403 VR, ROTARY, 20KB, L25, SHAFT, FLAT,
RV09ACF-40-25F
4751-1270+0 4
VR404 VR, ROTARY, 20KB, L25, SHAFT, FLAT,
RV09ACF-40-25F
4751-1270+0 4
K401 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
K402 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
K403 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
K404 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
K405 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
CN07A CONN, FFC, 20 PIN, P=1.0MM (HORIZONTAL) 2101-3051+0 4
CN08A CONN, FFC, 20 PIN, P=1.0MM (HORIZONTAL) 2101-3051+0 4
CN09A CONN, FFC, 20 PIN, P=1.0MM (HORIZONTAL) 2101-3051+0 4
