Bose FreeSpace DXA 2120 Service Manual

19
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Resistors
Reference
Designator
Description Vendor Part Number Note
R201 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R202 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R203 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R204 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R205 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R206 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R207 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R208 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R209 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R210 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R211 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R229 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R230 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R231 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R232 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R233 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R234 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R235 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R236 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R237 560 OHM, RMG, 1/16W, 5%, 0603/1608 4723-561J+P 4
R238 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J+P 4
R239 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R240 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R241 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R242 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R243 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R244 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R245 560 OHM, RMG, 1/16W, 5%, 0603/1608 4723-561J+P 4
R246 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J+P 4
R247 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R248 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R249 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R250 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R251 560 OHM, RMG, 1/16W, 5%, 0603/1608 4723-561J+P 4
R252 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J+P 4
R253 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R254 1.58K, RMG, 1/16W, 1%, 0603 4723-1581+P 4
R255 12.1K, RMG, 1/10W, 1%, 0805 4720-1212+J 4
R256 560 OHM, RMG, 1/16W, 5%, 0603/1608 4723-561J+P 4
R257 47K, RMG, 1/16W, 5%, 0603/1608 4723-473J+P 4
R258 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R260 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R261 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R262 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R263 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
R264 10K, RMG, 1/16W, 5%, 0603/1608 4723-103J+P 4
